- Isolating Sub-Hertz Vibration
DVIA-T series provides excellent vibration isolation performance in 1-10Hz, where the low frequency vibration critically disturb nanoscale measuring tools. The vibration control range of DVIA-T series starts from 0.5Hz, achieving 90% vibration isolation at 2Hz.
- Automatic Leveling to Payload Weight
If there are changes in an environmental and location or placing other instruments, users can adjust a level of DVIA-T by simply pressing a button.
- Portable Design
The smallest model is 420mm x 500mm x 93mm which weighs only 25kg, allowing user to hand carry and install on any place at all.
- Optimal Vibration Solution
Our own software provides the optimized vibration solution by employing the software to tune the feedback and feed forward control systems depending on users’ instruments weight and environments, if required by users.
- It’s Simple. Plug and Play!
DVIA-T incorporating a Plug & Play operating system, allowing users to use all functions by simply plugging a power cable into AC power and pressing buttons
|
- Real-Time Monitoring
With the GUI software and integrated active sensors allow users to monitor real time vibration levels and isolation performance. Furthermore, an LCD display on the front side of DVIA-R, enables users to monitor the automatic leveling and real time vibration levels.
- No Air
Metal springs are integrated in DVIA-T series as to reduce high frequency vibrations and compressed air is not required.
|
